Expertise

Background:

• Journeyman Tool & Die Maker
• 23 years of machine and fab experience
• Project management start to finish
• Micro to large assemblies

• Product Design start to finish
• Component design
• Design for Manufacturing
• Die Building and trouble shooting
• Mold Building and trouble shooting

Fixture design and building

• High Production
• One off
• Pneumatic
• Manual

Capabilities

01/ Engineering

CAD modeling and design

Fixture design

New product/component design

Product/component redesign

Fusion 360 Modeling

3D Printing

02/ Product Development

Manufacturing process

Tooling Design

Design for Manufacturing

New product development

04/ Capabilities Welding

TIG

• Steel/Stainless  maximum of 1+" multi-pass
• Aluminum to a maximum of 1+" multi-pass
• Steel/Stainless minimum of .020"
• Aluminum minimum of .030"


MIG

• Steel/Stainless  maximum of 3/4" multi-pass
• Steel/Stainless minimum of .030"


PLASMA

• Steel/Stainless/Aluminum max 3/4"


03/ Capabilities Machining & Fab

CNC Milling: 20"Y x 40"X x 20"Z

Manual Milling: 12"Y x 30"X x 17"Z

Manual Lathe: dia 14" swing x 26" between centers

Finger brake: 52" mild steel max 16 gauge

Shear: 52" mild steel max 16 gauge

Roller: 52"
